307
7. Check the inside of the element by illuminating with a
light bulb and if any pores or thinned parts are found,
replace the element.
8. Clean inside the dust pan (2) and the rubber cup (5).
9. Remove the cloth or tape from the air connector at the
back of the air cleaner body (4).
10. Insert the cleaned element (3) into the air cleaner body
(4).
11. Mount the dust pan (2) by matching the arrow to the
mating mark on the air cleaner body (4).
12. Secure the clamps (1) (3 places).
13. See “OPERATION 1.9 RADIATOR GRILL” and install
the radiator grill. See “OPERATION 1.12 OPERATION
SIDE COVER” and install the operation side cover.
