Maeda MC815C - TRANSPORT PRECAUTIONS; LOADING;UNLOADING PROCEDURES

To Next Page

To Previous Page

CAUTIONS WHEN PLACING OUTRIGGER

• Do not let people approach the machine when placing the

outriggers.

Otherwise, serious accidents such as feet being trapped

may occur.
