INTRODUCTION 2250 SERVICE/MAINTENANCE MANUAL
1-102
Published 11-06-15, Control # 040-13
350 psi
(24 bar)
RIGHT TRAVEL PUMP
LEFT TRAVEL PUMP
TO TRAVEL
MOTORS
T
T
HS54
RM-20
A
B
A
B
HS56
CRANE
DRUM 9
350 psi
(24 bar)
SWIVEL
SUCTION
MANIFOLD
SUCTION
MANIFOLD
HOIST CHARGE PUMP
A
B
B
A
BOOM
UP
DOWN
DOWN
UP
FROM BOOM
FLOW
FLOW
BRAKE LINE
FROM
FAN CIRCUIT
SERVO LINE
FIGURE 1-65
