ELECTRIC SYSTEM 2250 SERVICE/MAINTENANCE MANUAL
3-4
Published 11-06-15, Control # 040-13
Circuit
Breaker
Amps Wire No. Description of Items Protected
Engine Junction Box For Cummins N15-E450 and Cat 3406C Power Plants
CB-1 15 5B Electronic Control Module (Cummins) Ignition Relay
CB-2 120 5 Main System 12-Volt Power
CB-1
CB-2
268409_2
268409_1
FIGURE 3-3
