Manitowoc 2250 Service And Maintenance Manual

Reference Only
Manitowoc Published 11-06-15, Control # 040-13 3-35
2250 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
89L4 A-08 Left Pendant Cylinder Limit Switch 12 Volts Nominal (AI)
89P4 A-23 Rear Drum Pawl Limit Switch 12 Volts Nominal (AI)
89YY E-20 RCL Override (CE Option Only) 12 Volts Nominal (DI)
90CR C-08 Pendant Cylinder Extend Solenoid 12 Volts Nominal (DO)
90DR C-09 Pendant Cylinder Retract Solenoid 12 Volts Nominal (DO)
90QL A-20 Left Pendant Cylinder Rod Pressure Sender 1.2 Volts at 300 psi; 1 Volt at 0 psi (AI)
90QM A-36 Mast Accumulator Pressure Sender 1.2 Volts at 300 psi; 1 Volt at 0 psi (AI)
90QR A-21
Right Pendant Cylinder Rod Pressure
Sender
1.2 Volts at 300 psi; 1 Volt at 0 psi (AI)
90RP A-24
Right Pendant Cylinder Piston Pressure
Sender
1.2 Volts at 300 psi; 1 Volt at 0 psi (AI)
99B A-22 Counterweight Level Sensor 5 Volts at 0°; 0.5 Volts Change Per 1° (AI)
