HOISTS 2250 SERVICE/MAINTENANCE MANUAL
5-2
Published 11-06-15, Control # 040-13
FIGURE 5-1
A03641
View at Right Rear Drum
(Other Drums Similar)
3
1
5
9
2
Item Description Item Description
1 Lever 6a Roller
2 Rollers 7 Lock Nut
3 Cap Screw 8 Adjusting Screw
4 Drum 9 Return Spring
5 Mounting Bracket 8 Eyebolt
6 Limit Switch
2
A644
1
3
3 to 4 Wraps of Wire
Rope on Drum
4
7
8
4
6a
6
10
