HOISTS 2250 SERVICE/MAINTENANCE MANUAL
5-10
Published 11-06-15, Control # 040-13
Left Rear Drum Brake
(all other drum brakes similar)
FIGURE 5-7
End of Piston Rod Must be
Flush with Inside of Rod End
VIEW C
(typical each rod end)
1-9/16 to 2-1/16 in (40 to 52 mm)
Working Brake Released
Parking Brake Applied
A467
Item Description
1Guard
2 Band Support
3 Jam Nut and Adjusting Nut
4 Access Cover
5 Band Adjusting Nut
6Bane
7 Lining
8Live End
9 Brake Actuator
10 Support
11 Mounting Nut
12 Brake Lever
13 Dead End
14 Washer
15 Brake Release Bolt
16 Cover (Past Production)
17 Piston Rod
18 Jam Nut
19 Rod End Pin
20 Rod End
1
2
3
4
5
6
7
9
11
12
13
14
2
10
15
16
17
19
18
20
VIEW A
Current Production
2.0 to 2-1/2 in (51 to 64 mm)
Working Brake Released
Parking Brake Applied
VIEW B
Past Production
192773-1
20
8
