Reference Only
Manitowoc Published 11-06-15, Control # 040-13 7-27
2250 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
FIGURE 7-29
Disengage
Engage
1/8 in
(3 mm)
View B
27-1/2 in
(699 mm)
View A
No Interference
Either Side
27-7/8 in
(327 mm)
Item Description Item Description
1 Latch Assembly 8 Hex Nut
2 Hook 9 Shift Rod
3 Base Plate 10 Ball Joint
4 Rocker Arm 11 Elastic Stop Nut
5 Set Screws 12 Pull Rod
6 Spring 13 Squeeze Trigger
7 Control Rod 14 Left Rear Jacking Cylinder
9
1
2
3
4
7
5
6
8
11
10
12
11
2
1
1
14
13
2
