PROBLEM 13
Front or rear load drum will not reach maximum speed.
POSSIBLE CAUSES
Partial control from handle to PC; Partial control voltage
from PC to pump EDC; Pump or motor is bad.
CHECKS
When moving load drum control handle fully in both directions, diagnostic display DRUM
1, 2 or 3 screen (bank 1) obtains 100% pump control in each direction?
Yes
No
When moving load drum handle fully in both directions, diagnostic
display DRUM 1, 2 or 3 screen (bank 2) obtains 100% pump control in
each direction?
Repair or replace
control handle.
Check for control voltage of +2.3 volts or more and coil
resistance of 15 to 19 ohms at pump EDC. (See Te s t
5.)
Consult dealer/factory.
Yes
Voltage and
Coil Ok
Remove plug at motor port M5 and check
orifice for obstruction. (See Te s t
7.)
Repair or replace coil or wiring.
Obstruction No Obstruction
Clean or replace
orifice.
Check pump and motor for
leakage. (See Te st
8.)
Repair or replace pump or motor.
Voltage and/or
Coil not Ok
No
To Next Page
