PROBLEM 23
Gantry cylinders will not raise or lower.
CHECKS
Does system pressurize to 3,500 psi when moving gantry switch
from neutral to lower position at remote controller?
POSSIBLE CAUSES
Switch failure; Solenoid failure; Mechanical problem;
Wiring problem; Cylinder failure.
Yes
No
Are mechanical problems present at
gantry cylinders?
Yes
No
Enable gantry extend and retract solenoid valves
and check that voltage is present.
Voltage
No Voltage
Check for 12 volts at gantry power switch, wire
#43 for raise or #44 for lower.
Voltage
No Voltage
Repair
problem.
Adjust cylinder counterbalance
valve. (See Tes t
22.) Does cylinder
operate correctly?
No
Replace cylinder or consult dealer/factory.
Check wiring to solenoid
and replace, if necessary.
Check appropriate diode to wire #89D1.
Diode good Diode bad
Replace solenoid valve section. Replace diode.
Replace power switch fuse F13.
To Next Page
