Reference Only
Manitowoc Published 11-06-15, Control # 040-13 1-61
2250 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
RF-29
AUXILIARY SYSTEM
SUCTION
MANIFOLD
RELIEF VALVE
HS-12
AUXILIARY PUMP
FAN PUMP
8
8
8
8
300 psi
(21 bar)
2000 psi
(138 bar)
FAN CIRCUIT WITH
CATERPILLAR ENGINE
DISABLE
HS-21
HS-22
UPPER ACCESSORY VALVE
TO LOWER
ACCESSORY
VALVES
AUXILIARY SYSTEM
SUCTION
MANIFOLD
RELIEF VALVE
HS-12
AUXILIARY PUMP
FAN PUMP
8
8
8
8
300 psi
(21 bar)
2000 psi
(138 bar)
FAN CIRCUIT WITH
CATERPILLAR ENGINE
DISABLE
HS-21
HS-22
UPPER ACCESSORY VALVE
TO LOWER
ACCESSORY
VALVES
REAR ADAPTER FRAME PINS
FRONT ADAPTER FRAME PINS
ENGAGED
ENGAGE
FRONT ADAPTER FRAME PINS
REAR ADAPTER FRAME PINS
DISENGAGE
DISENGAGED
HS-24
HS-23
HS-24
HS-23
RF-28
PILOT PRESSURE
PILOT PRESSURE
X
X
FIGURE 1-35
(PAST PRODUCTION)
(PAST PRODUCTION)
