Manitowoc Grove GMK4100L-1 User Manual

Operating elements for driving
3.2 Short description of the operating elements
Operating manual 3 302 690 en 3 - 45
GMK4100L-1
23.11.2017
CCS display
Adblue filling level indicator
3.2.5 Battery master switch
– Display Green: Over 10% – over 4 l (0.9 gal)
Yellow: 5 to 10% – 2 to 4 l (0.4 to 0.9 gal)
Red: Below 5% – less than 2 l (0.4 gal)
à p. 4 - 7
– To switch on: Push up
– To switch off: unlock and then press in downwards
à p. 4 - 9
