1.5 Technical data
1 - 10 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
1.5.4 Dimensions and weights of removable parts
This section contains the dimensions and weights of the parts that can be
removed for on-road driving;
à Driving modes, p. 6 - 1.
Spare wheel
Outrigger
Description
Length x width x height
in m (ft)
Weight in kg
(lbs)
Spare wheel 385/95 R 25 1.36 x 1.36 x 0.40
(4.45 x 4.45 x 1.30)
245
(540)
Spare wheel 445/95 R 25 1.50 x 1.50 x 0.45
(4.95 x 4.95 x 1.50)
332
(732)
Spare wheel 525/80 R 25 1.50 x 1.50 x 0.53
(4.92 x 4.92 x 1.74)
362
(798)
Description
Diameter x Height
in m (ft)
Weight
in kg (lbs)
Plastic outrigger pad
diameter
0.50 x 0.16 (1.64 x 0.52)
22 (48.5)
Steel outrigger pad
diameter
0.50 x 0.16 (1.64 x 0.52)
30 (66.1)
Front outrigger
1)
,
complete per packet
2.50 x 0.30 x 1.05
(8.20 x 0.99 x 3.45)
650 (1,435)
Rear outrigger
1)
,
complete, per packet
2.50 x 0.30 x 1.05
(8.20 x 0.99 x 3.45)
750 (1,655)
1)
Consists of two sets
