Manitowoc Grove GMK4100L-1 User Manual

Operating elements for crane operation
9.2 Short description of the operating elements
Operating manual 3 302 690 en 9 - 91
GMK4100L-1
23.11.2017
9.2.3 Engine
Side panel à Starting the engine – from the crane cab, p. 10 - 3.
Ignition lock
Starting the engine
– The engine must be off:
Set idling speed
– The engine is running
:
Left control lever
– The engine must be off:
s
–0 Ignition off, engine off, key can be removed
–1 Ignition on and power supply on for:
instrument lighting, CCS, engine control system, RCL
à p. 10 - 7
– Press upwards once: Engine starts,
Idling speed = standard
– Press up: Increase idling speed
– Press down: Decrease idling speed,
engine cutout after about 6 seconds.
à p. 10 - 9
– Press and keep
depressed:
Engine starts,
Idling speed = standard
