Driving
5.5 Separate steering
5 - 60 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
5.5.1 Switching to separate steering
Always switch to separate steering when
– Driving with the rigged truck crane
– steering at low speed.
You can switch to separate steering only at low speeds.
• Open the Driving (1) menu.
• Select and confirm the symbol for the
desired steering mode.
– The symbol (2) indicates the steering mode
that is engaged.
– The symbols (1) are red – steering unlocked.
H
When separate steering is switched on, the speed is limited to
approx. 20 km/h (12 mph).
If the error symbol is displayed, contact
Manitowoc Crane Care; Ã p. 8 - 24.
G
Risk of accidents when driving on-road with unlocked steering
After driving with separate steering, change over immediately to normal
steering mode. The locking status for normal steering mode is only
restored once the on-road driving symbol is displayed.
4 When driving around corners, the
3rd and 4th axle lines are steered
automatically
5 In crab travel mode, the 3rd and 4th
axle lines are steered automatically
3 Manual mode, the 3rd and 4th axle
lines are manually steered for driving
around corners/crab travel mode
