Driving
5.5 Separate steering
Operating manual 3 302 690 en 5 - 61
GMK4100L-1
23.11.2017
Automatic separate steering
• Steer the 1st and 2nd axle line with the steering wheel.
The electronics will register the steering angle on the 1st and 2nd axle lines
and steer the wheels of the 3rd and 4th axle lines correspondingly.
(A) – When driving around corners
The 3rd and 4th axle lines are steered in line
with the turning radius, contrary to the steer-
ing angle of the 1st and 2nd axle lines.
(B) – For crab travel mode
The 3rd and 4th axle lines are steered in the
same direction as the 1st and 2nd axle lines.
Steering with manual separate steering
• Steer the 1st and 2nd axle line with the steering wheel.
• Steer the 3rd and 4th axle line with the button (1).
The axle lines are steered as long as you keep the button pressed or until an
end position is reached.
s
– To turn to the left: • Push the button to the left.
– To turn to the right:
• Push the button to the left right.
