Malfunctions in driving mode
8.4 Troubleshooting
Operating manual 3 302 690 en 8 - 19
GMK4100L-1
23.11.2017
8.4 Troubleshooting
8.4.1 Malfunctions on the engine
H
In addition to this information; à Separate engine operating instructions,
provided by the manufacturer
.
.
Malfunction Cause Solution
Engine does not start –
Starter does not turn
Battery master switch is
switched off
Switch on the battery
master switch;
à p. 4 - 9
Switch the ignition off
à Switch the ignition on,
p. 4 - 9
Transmission not in neutral
position
à Switching the
transmission to the neutral
position
, p. 5 - 26
Parking brake released Lock the parking brake;
à p. 5 - 46
Fuse F1/1, F1/2 blown Replace blown fuses;
à p. 8 - 49
Emergency stop switch
pressed
Release the emergency stop
switch;
à p. 4 - 19
Engine does not start –
Starter turns
Batteries insufficiently
charged
Charge the batteries;
à Maintenance manual
The symbol is displayed Fuel tank empty 1. Refuel;
à p. 4 - 5
2. Bleed the fuel system;
à Maintenance manual
à Separate engine operating
instructions, provided by the
manufacturer
The symbol is displayed Air intake inhibitor closed à Releasing the air intake
inhibitor
, p. 4 - 20
The lamp does not light
after the ignition is
switched on when the
engine is cold
Fuse F6/8 blown Replace blown fuses;
à p. 8 - 49
The symbol is displayed Air filter clogged Replace the dry air filter;
à Maintenance manual
The symbol is displayed Coolant level too low Top up coolant;
à Maintenance manual
