Driving
5.5 Separate steering
Operating manual 3 302 690 en 5 - 63
GMK4100L-1
23.11.2017
5.5.2 Switching to normal steering mode
After driving with separate steering, change over immediately to normal
steering mode.
Switching off the separate steering is possible during standstill and while
travelling, up to a speed of approx. 5 km/h (3 mph).
• Select and confirm the symbol (1).
The
Driving menu opens.
• Turn the wheels to the Straight ahead position
– current wheel position is displayed.
• Select and confirm the symbol (2) – display
symbol (3).
After the switchover to normal steering mode
the symbols (1) turn green – steering locked.
If the symbols (1) are yellow:
Depending on the steering mode, steer using
the steering wheel (5) or the button (4) until
the symbols (1) turn green
If the error symbol is displayed, contact
Manitowoc Crane Care; Ã p. 8 - 24.
