Driving
5.3 Driving the truck crane and switching it off
5 - 46 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
5.3.7 Switching the truck crane off
To switch the truck crane off, you must:
Secure it against
rolling away
The number of wheel chocks supplied varies according to country.
Transport at the rear of the carrier
• Push the chock (2) behind the bracket (3) and
hang it on the holder (1).
(A) – Folding out
• Push the latch (4) through the hole (5).
The chock unfolds by spring force.
(B) – Folding up
Push the chock together until the latch (4)
engages in the hole (5).
1. Stop the truck crane
2. Apply the parking brake
3. Switch to neutral position;
à p. 5 - 26
4. Turn off the engine;
à p. 4 - 18
G
Risk of accidents by truck crane moving unintentionally
On uphill and downhill gradients secure the truck crane using wheel chocks
in addition to the parking brake.
