Rigging work
12.8 Outrigger operation
Operating manual 3 302 690 en 12 - 41
GMK4100L-1
23.11.2017
12.8.2 CHECKLIST: Retracting the outriggers
H
This checklist is not a complete operating manual. There are accompanying
operating instructions which are indicated by cross-references.
Observe the warnings and safety instructions specified here!
1. Retract the outrigger cylinders as far as possible;
à p. 12 - 54.
2. Move the outrigger pads into the driving position and secure them;
à Moving into driving position, p. 12 - 51.
3. Fully retract and secure all supports;
à For on-road driving, p. 12 - 47,
à Extending/retracting outrigger beams, p. 12 - 47.
4. Stow away packing material safely, if applicable.
5. Switch on suspension (release locking) – symbol green (suspension
on);
à p. 5 - 17.
s
