Operating elements for crane operation
9.2 Short description of the operating elements
9 - 150 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
9.2.25 Hand-held control
Sockets for hand-
held control
The following applies to all sockets:
The hand-held control is only active when it is connected to the
sockets (1)or (2).
– Pull plug: Engine off – ignition off
– Insert plug: Switch the ignition on
à p. 12 - 23
Enabled operations
1 – Emergency operation for crane movements (except for telescoping
mechanism)
– Derrick lattice extension
1)
2 – Emergency mode for crane operations
1)
Additional equipment
