Crane operation
11.4 Operation of the rated capacity limiter
11 - 30 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
11.4.1 Switch on the RCL
Switching on The RCL is switched on together with the ignition.
• Switch on the ignition.
A test program runs after switching on the ignition.
• Check whether you can hear a buzzer tone.
Lamp test
• Check that the lamps (1) light up after
turning on the ignition.
If one or more lamps do not light up, refer to
Manitowoc Crane Care.
Brightness of the displays
The brightness of the
CCS and RCL is adjusted automatically.
Do not cover the sensors (1) and keep them clean to avoid contamination
that can affect the brightness adjustment.
You can set a common minimum brightness for both displays at the
CCS
control unit. This is operated in the same way as in the driver's cab;
à p. 4 - 11.
G
Risk of accidents in the event of faulty safety devices!
If the lamps or buzzer fail, notify
Manitowoc Crane Care and have the error
corrected.
In the meantime, pay particular attention to the lamps in the event of a fail-
ure of the buzzer tone and vice versa.
