Rigging work
12.9 Rigging/unrigging the counterweight
12 - 74 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
12.9.4 Slinging points on the counterweight sections
•
Only use lifting gear of sufficient load bearing capacity.
Weights;
à Counterweight parts, p. 1 - 14.
Sections
• Attach the counterweight sections at the
slinging points (1).
Blocks
• Sling the blocks at the slinging points (1).
G
Risk of accident if used improperly
Attach the lifting gear to various counterweight section only at the appro-
priate slinging points. Ensure the lifting gear has sufficient load bearing
capacity.
