Manitowoc Grove GMK4100L-1 User Manual

Overview
1.5 Technical data
1 - 14 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
Counterweight
parts
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Auxiliary hoist
Description
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
0.8 t counterweight section 0.60 x 1.11 x 0.24
(1.97 x 3.64 x 0.79)
800
(1,764)
2.7 t base plate 1.34 x 2.53 x 1.15
(3.15 x 8.40 x 1.87)
2,700
(5,953)
1.0 t counterweight section 1.34 x 2.53 x 0.16
(3.15 x 8.40 x 0.5)
1,000
(2,205)
7.1 t counterweight section 1.34 x 2.53 x 0.54
(3.15 x 8.40 x 0.82)
7,100
(15,653)
1.5 t counterweight section 1.14 x 0.86 x 0.34
(3.15 x 8.40 x 0.82)
1,500
(3,307)
2.2 t counterweight section 1.34 x 2.53 x 0.18
(3.15 x 8.40 x 0.82)
2,200
(4,850)
4.0 t counterweight section 1.34 x 2.53 x 0.28
(3.15 x 8.40 x 0.82)
4,000
(8,820)
2.4 t counterweight pieces,
each
0.97 x 0.82 x 0.92
(3.15 x 8.40 x 0.82)
2,400
(5,291)
1)
There may be deviations of up to ± 3% due to the manufacturing
procedure.
Description
Length x width x height
in m (ft)
Weight
in kg (lbs)
Complete auxiliary hoist 0.90 x 1.50 x 0.70
(3.00 x 4.95 x 2.30)
1,050
(2,315)
