Malfunctions during crane operation
14.4 Troubleshooting
14 - 24 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
14.4.18 Malfunctions on the CraneSTAR system
If an error is present, then check the fuses and the electronic connections.
Checking
• Loosen the bolts (2) and remove the
cover (1).
• Check the associated fuse on the plate (3)
and replace it if necessary:
à Fuses in the
crane cab
, p. 14 - 73.
• Loosen the screws (4) and fold down the
plate (3) to the front.
S
Risk of damage if procedure is incorrect
Observe the following notes to avoid malfunctions and damage.
– Always switch the ignition off before changing a fuse and before check-
ing the antenna plugs.
– Replace blown fuses only with new fuses of the same amperage.
