Operating elements for driving
3.2 Short description of the operating elements
3 - 74 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
3.2.23 Windows and doors
Window winder
Button assignment
Movement stops after the button is released
and when an end position is reached.
Jog function
Press button (1) briefly – the window opens all
the way to the end position.
Press button (2) briefly – the window closes all
the way to the end position.
G
Risk of crushing when closing the windows
If the window winders encounter resistance, they do not stop but keep on
moving at reduced power.
A Window winder, driver's door
B Window winder, passenger door
1 To open the window
2 To close the window
