Malfunctions in driving mode

8.7 Fuses on the carrier

8 - 52 3 302 690 en Operating manual

GMK4100L-1

23.11.2017

Designation Amperage (A) Function

F4/1 3 Cab lighting

F4/2 20 Dual tank switchover

F4/3 5

CCS display

F4/4 - Unassigned

F4/5 - Unassigned

F4/6 - Unassigned

F4/7 - Unassigned

F4/8 - Unassigned

Designation Amperage (A) Function

F5/1 20 Auxiliary heater

F5/2 3

Control unit UE CCM 11

Control unit UE 2 IOL 31/32/33

F5/3 10 Radio

F5/4 5 Tachograph, instrument panel

F5/5 10 Fan

F5/6 - Unassigned

F5/7 - Unassigned

F5/8 5 Power supply relay
