Manitowoc Grove GMK4100L-1 User Manual

Malfunctions in driving mode
8.7 Fuses on the carrier
Operating manual 3 302 690 en 8 - 55
GMK4100L-1
23.11.2017
Designation Amperage (A) Function
F10/1 5
Turn signal indicators
Light switch
F10/2 10 Rotating beacon carrier/superstructure
F10/3 5
Parking light
Side marker lights
Side marker lights, front
F10/4 3 Instrument lighting
F10/5 5
Brake lights
Trailer brake lights
F10/6 10
Light switch
Warning blinkers
F10/7 - Unassigned
F10/8 5 Reversing lamp
