Crane operation
11.4 Operation of the rated capacity limiter
Operating manual 3 302 690 en 11 - 33
GMK4100L-1
23.11.2017
Enter the slewing
range type
Possible types are the Standard slewing range type and, with the corre-
sponding equipment, the
MAXbase slewing range type.
Different lifting capacity tables apply depending on the entered slewing
range type and these then influence further input of the rigging mode.
–
Standard slewing range type
The standard lifting capacity tables provided in printed form with the truck
crane apply. All rigging modes listed there can be entered.
– The rigging mode can be specified via entry of the reeving and
RCL code or via the individual components.
– In the case of individual components, the outriggers are always
entered as complete outrigger span.
– In the case of individual components, the slewing range is entered
according to the
lifting capacity table.
–
MAXbase slewing range type
The MAXbase tables apply, which are only provided in digital form due to
the wide diversity of configurations. All rigging modes listed there can be
entered.
– The rigging mode is entered via the individual components.
– The outriggers are entered as individual widths for each outrigger
beam.
– The enabled slewing range is displayed, divided into four areas with
different lifting capacities.
