Manitowoc Grove GMK4100L-1 User Manual

Rigging work
12.9 Rigging/unrigging the counterweight
Operating manual 3 302 690 en 12 - 77
GMK4100L-1
23.11.2017
6. Slew the superstructure into the 180° to the forwards position and lock it;
à Braking the slewing movement, p. 11 - 119
à Locking/unlocking the superstructure, p. 11 - 15.
7. – Open
Counterweight menu
– Correct the rigging mode, if necessary;
à p. 12 - 87,
– Slew the superstructure into the rigging range and lift counterweight
to the turntable (automatic) and pre-charge;
à p. 12 - 89.
8. Enter the current rigging mode with the new rigged counterweight
combination at the RCL display;
à p. 11 - 32.
9. Only switch on the slewing gear if slewing is permissible for the current
outrigger span;
à Slewing with rigged counterweight, p. 12 - 97
