Rigging work
12.10 Rigging work on the main boom
12 - 124 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
Removing the right lifting limit switch
• Pull out the plug and close the socket with
the protective cap (1).
• Remove the lifting limit switch (4) from the
bracket (2)
• Attach the retaining pin (3) to the lifting limit
switch.
