Malfunctions during crane operation
14.3 Warning and error messages
14 - 10 3 302 690 en Operating manual
GMK4100L-1
23.11.2017
– Lattice extension angle too small
Raise the lattice extension;
à Lattice extension operating manual.
– Lattice extension angle too large
Lower the lattice extension;
à Lattice extension operating manual.
– Boom extension angle not measured (different sensor values)
– Main boom, load capacity chart not present
– Lattice extension, load capacity chart not present
– RCL override (switch 1) not actuated
– RCL override (switch 1) actuated
– RCL override (switch 2) not actuated
– RCL override (switch 2) actuated
