MD Helicopters MD Explorer - Page 929

CSP−900RMM−2MD Helicopters, Inc.
ROTORCRAFT MAINTENANCE MANUAL
Page iii
Revision 36
32 Contents
TABLE OF CONTENTS (Cont.)
Para/Figure/Table Title Page
4. Inspections for the Standard Landing Gear Assembly 605.........................
A. Aft Crosstube Inspection 605
.................................................
Table 601. Maximum Aft Crosstube Spread 605................................
Figure 605. Forward Crosstube Measurement 606..............................
B. Forward Crosstube Inspection 606............................................
Table 602. Maximum Forward Crosstube Spread 607..........................
C. Forward Spacer Fitting Inspection 607........................................
Figure 606. Forward Spacer Fitting Inspections 607............................
Figure 607. Damper Fluid Level Indicator 608.................................
D. Fluid Level Check of the Landing Gear Damper Assemblies 608.................
Figure 608. Damper Inspection 609...........................................
E. Landing Gear Damper Assembly Inspection 609...............................
Figure 609. Skid Tube Inspections 610........................................
F. Skid Tube Assembly Inspection 611...........................................
G. Inspection of the Mating Surfaces of the Crosstubes and Stop-Clamps 612
.......
H. Inspection of the Internal Surfaces of the Crosstubes 612
.......................
Figure 610. Insertion Points for the Aft and Forward Crosstubes 613............
Repairs 801......................................................................
1. Landing Gear Damper Assemblies 801..........................................
A. Drain Port Repair 801.......................................................
Figure 801. Location of Damper Drain Ports 801...............................
Figure 802. Skid Tube Repairable Sections 802.................................
2. Left-Hand and Right-Hand Skid Tube Assemblies 802...........................
A. Blend Repair 802............................................................
Figure 803. Location of the Nonslip Surfaces 803...............................
3. Nonslip Surfaces 803..........................................................
A. Repair and Installation 803..................................................
Figure 804. Repair of the Aft Crosstube 804...................................
4. Aft Crosstube 805.............................................................
A. Inspection and Blend Repair of Corrosion, Dents, Nicks, and Scratches 805.......
Figure 805. Repair of the Forward Crosstube 806..............................
5. Forward Crosstube 807........................................................
A. Inspection and Blend Repair of Corrosion, Dents, Nicks, and Scratches 807.......
Figure 806. Insertion Points for the Aft and Forward Crosstubes 808
............
6. Apply Corrosion Inhibitor to Internal Surfaces of Crosstubes 809
..................
A. Aft Crosstube 809
...........................................................
B. Forward Crosstube 809
......................................................
