reference level, removing the need to ramp up and allowing the tester to reach the target
voltage faster.
Figure 20. Single-coil testing submenu example.
In this example, the Surge test three-phase coil mode submenu is shown.
Figure 21. Surge test mode submenu example.
When you touch the Reports icon then the Display icon in the Mode Menu, the mode
submenu displays the icons shown below. As you can see in this example, some icons are simply
presented in text. Their functions are self-explanatory.
Figure 22. Reports submenu example.
