MGB.
Issue4.
65891
H.3
6.4.4.4"
Z
Vr-nkoooax'd—i
HF!
oim'
I—tv—l
14.
15.
16.
17.
18.
19.
Description
Caseassembly.
Nut—bearing
retaining—R.H.T.
Nut
—bearing
retaining—L.H.T.
Stud—gear
carrier.
Nut—rebound
spindle.
Washer—bearing
retaining
nut.
Nut—gear
carrier
to
axle
case.
Washer—spring—nut.
Plug—drain.
Plug—ller.
Breather
assembly.
Joint—gear
carrier
to
axle
case.
Carrier
assembly.
Stud—bearing
cap.
Washer—plain—bearing
cap.
Washer—spring—bearing
cap.
Nut—stud.
Bearing—differential.
Washer—bearing-—packing—.002
to
.010 in.
(.051
to
.254
mm.).
KEY
TO
THE
REAR
AXLE COMPONENTS
No.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
Description
Cage—differential.
Wheel—differential.
Washer—irust—differential
wheel.
Pinion—differential.
Washer—thrust—differential
pinion.
Pin—pinion.
Peg—pinion
pin.
Crown wheel
and pinion—11/43.
Bolt—crown
wheel
to
differential
cage.
Lock
washer—bolt.
Washer—pinion——thrust—.ll2
to
.126
in.
(2.85
to
3.20
mm.).
Bearing—pinion—inner.
Spacer—bearing.
Bearing—pinion—outer.
Shim—outer
bearing—.004
to
.030
in.
(.102
to
.762
mm.).
Seal-oil.
Cover—dust.
Flange—universal
joint.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
55.
Description
Nut—pinion.
Washer—spring—nut.
Shaft—axle
(disc
wheels).
Shaft—axle
Hub
extension—RH.
(wire
wheels).
Hub
extension—L.H.
Plug—welch—hub
extension:
J
oint—shaft
to
hub.
Screw—countersunk—shaft
to
hub.
Hub
assembly
Stud—wheel
(disc
wheels).
Nut—wheel
stud
Spacer—bearing
Hub
assembly
1
(wire
wheels).
Stud—wheel
J
Ring—oil
seal.
Seal—hub.
Bearing—hub.
