MIMAKI JV330 Series User Manual

Chapter 2 Printing
68
8
Lower the clamp lever.
• Hold the media with the pinch roller and grit rollers.
9
Lock the media stopper.
• "Using the Media Stopper"(P. 65)
10
Move to the front of the machine and open the front cover.
11
Raise the clamp lever and pull out the media.
• Make sure the media does not fall to the rear.
• Adjust the rear roll holder position so that the media does not cover the right-hand slit line
on the platen. Movement at an angle may result in damage to the print head.
Slit line
Media
Media holder
• The areas extending 5 mm from both sides of the media are margins.
12
(CJV only) Lower the clamp lever to confirm that the spacing from the pinch roller is uniform.
• "Adjust the Pinch Roller Positions."(P. 56)
• If the spacing is not uniform, repeat all steps from the start.
13
(CJV only) Raise the clamp lever.
