4.6.7.3 Connection diagram for a master with three slaves
NOTICE
The cable screens must be guided into the instrument through the cable glands and
connected to terminal in terminal contact 3 (S); see connection diagram.
Before, during and after installation, make sure that the sealing rings are seated
correctly.
