Lynx II DSA User's Manual – 7096089 vii
Preface
The Lynx
®
II Digital Signal Analyzer (DSA) is a
fully integrated 32K channel signal analyzer
offering advanced signal processing filters and
digital stabilization.
With its multiple counting modes, including PHA,
MCS, time stamped list, and multi-spectral
scaling, Lynx II supports virtually every counting
application right out of the box. All current
spectroscopy detector types are supported by the
built-in triple-range dual-polarity HVPS.
This User's Manual is intended for the readers who
will use the Lynx II in their facility to acquire
spectroscopic data; the installer or technician who
will initially set up the system with other
measurement and network equipment; and for the
person who may infrequently make a sophisticated
adjustment to a parameter or setting.
Figure 1 Front View of Lynx II DSA
Setup is designed to be simple, and its web-enabled setup and operation provide live spectral
display/control, energy calibration, and basic analysis.
Because the Lynx II is designed to be operated in a diversified computing environment, it
supports multiple modern communications technologies using 10/100/1000 Ethernet for easy
LAN or WAN access. USB support is also provided for specialized applications and legacy
support.
The Primary User Interface - an advanced browser-based design - allows interaction with your
Inputs from almost any computer device equipped with an Internet browser, whether locally or
remotely. This minimizes the connectivity requirements for all users.
A separate Lynx II Programming Libraries document is available. Ask your local
representative for more information about the Programming Libraries, if required.
