Manual Inhibit Mode
Lynx II DSA User's Manual – 7096089 179
F. Rack-mounting Your Lynx II
Note: Disassembly of the Lynx is not required to mount to the Lynx II.
Lynx II systems may be mounted in a conventional 19-inch equipment rack. An optional
rack mounting kit, LYNX-II-MOUNTKIT, is available. Refer to the following sections for
instructions on how to mount your Lynx II units.
Lynx II Rack Mounting Kit
One or two Lynx II units may be rack-mounted in 2U of a 19-inch equipment rack using
the following:
 Lynx II Half-Rack Bracket
 Lynx II Rack Blank
 M3 X 10mm LG SS 18-8 FHMS
 10-32 X 1/4IN, 316 SS FHMS
Figure 80: Several 2U Rows of Lynx II/Lynx Units in a 19-inch Rack
