13 - 5
13.1 Data Storage Location
13.1.4 Display file
13.1.4 Display file
The files that can be displayed in each screen are as follows.
*1 The 6 8 dot font, 12-dot numerical HQ font, 16-dot numerical HQ font are displayed as Standard monitor OS.
*2 The user-created screen data, comment data, and font data are displayed as project data.
*3 Each folder is created automatically at installation, download and upload of each file.
*4 The folder name and file name can be set at [System Setting] in [System Environment] of GT Designer2.
GT Designer2 Version Screen Design Manual
Section 3.1 GOT/PLC Type Setting
Contents
Display
screen
Storage location
(Drive name/folder name)
BootOS
OS
information
screen
Built-in flash memory C:\G1BOOT\
*3
Standard
monitor OS
Standard monitor OS system screen data
Built-in flash memory C:\G1SYS\
*3
Standard monitor OS system screen
management information file
Standard monitor OS (monitor function)
*1
6 8-dot font (ASCII characters)
12-dot numerical HQ font
16-dot numerical HQ font
TrueType numerical font
12-dot standard font
16-dot standard font
Extended function OS
Option OS
Communication driver
Project data
*2
Project
information
screen
Built-in flash memory C:\PROJECT1\
*3*4
User-created screen data
Comment data
12-dot HQ fonts (Mincho/Gothic)
16-dot HQ fonts (Mincho/Gothic)
TrueType (Mincho/Gothic)
Resource
data
Advanced alarm log file CSV file
Alarm
information
screen
Standard CF card A:\
With GT Designer2, any folder name or file name can be specified.

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
