14 - 1
14.1 Debug
14.1.1 Debug functions
9
UTILITY FUNCTION
10
COMMUNICATION
INTERFACE
SETTING
11
DISPLAY AND
OPERATION
SETTINGS
12
CLOCK SETTINGS
AND BATTERY
STATUS DISPLAY
13
FILE DISPLAY AND
COPY
14
GOT SELF CHECK
15
CLEANING OF
DISPLAY SECTION
16
INSTALLATION OF
BOOTOS AND
STANDARD MONITOR OS
14.
GOT SELF CHECK (DEBUG & SELF CHECK)
The GOT can display the screen for debugging or self-checking.
The following describes the functions available as the debugging and self-checking function.
14.1 Debug
This manual covers only an outline of the debugging function and operations until displaying the screen.
For display contents of each debugging function and operation method, refer to the following manual.
GOT1000 Series Extended/Option Functions Manual
14.1.1 Debug functions
The debug function includes functions for the PLC system status check and those for increasing the
efficiency in troubleshooting.
The following items can be realized with the debug function.
Items Contents Reference page
Debug System monitor, A list editor and FX list editor 14-1
Self check Memory check, Drawing check, Font check, Touch panel check and I/O check 14-3
System alarm
display
GOT errors, CPU errors 14-20
GOT start time Time when the GOT was started 14-22
Items Contents
System monitor
The device of PLC CPU or buffer memory of the intelligent function module can be monitored and tested.
A list editor The sequence program of ACPU can be list edited.
FX list editor The sequence program of FX PLC can be list edited.
To Next Page
