16.3 BootOS and Standard Monitor OS Installation Using CF Card
16.3.2 Installation method using the program/data control function (Utility)
16.3.2 Installation method using the program/data control function (Utility)
For details of program/data control function, refer to the following.
Chapter 13 FILE DISPLAY AND COPY (PROGRAM/DATA CONTROL)
Program/data control is a function to install OS files from the CF card to GOT by the Utility operation.
Precautions on executing program/data control function
When execute program/data control function, Standard monitor OS has to be
installed in GOT in advance. Thus, this function cannot be used for the initial
installation of Standard monitor OS after purchasing GOT.
Install Standard monitor OS by the following two methods.
(1) Method using GT Designer2
GT Designer2 Version Basic Operation/Data Transfer Manual
(2) Installation method when turning the GOT power on
Section 16.3.1 Installation method when the GOT is turned on
1 Operation procedure
1 Power OFF the GOT. After CF card access
LED is off, install the CF card in which
BootOS, Standard monitor OS or project
data is stored in the CF card interface of
GOT.
2 Switch ON the CF card access switch of
GOT.
3 Display the program/data control function
screen (Utility) on the GOT, and install
BootOS, Standard monitor OS from the CF
card to GOT.
Touch [Install].
To Next Page
