Mitsubishi GOT1000 GT11 - Option (Optional Components for GT11)

2 - 4
2.2 Component List
2.2.2 Option (Optional components for GT11)
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
PART NAME
5
EMC DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
2.2.2 Option (Optional components for GT11)
PLC connection cable (Sold separately)
*1: Description in parentheses indicates the cable side connector shape.
Product name Model name Cable length Contents
RS-422
Cable
FXCPU
direct
connection
cable
FX
expansion
board
connection
cable
GT01-C10R4-8P 1m
For connecting FXCPU (MINI DIN 8 pins) and
GOT.
For connecting FXCPU expansion board (MINI
DIN 8 pins) and GOT.
GT01-C30R4-8P 3m
GT01-C100R4-8P 10m
GT01-C200R4-8P 20m
GT01-C300R4-8P 30m
QnA/A/
FXCPU
direct
connection
cable
computer
link
connection
cable
GT01-C30R4-25P 3m
For connecting QnA/ACPU/Motion controller
CPU (A series) FXCPU (D-sub 25 pins) and
GOT.
For connecting FA-CNV
CBL and GOT
For connecting serial communication unit
(AJ71QC24(N)-R4) and GOT
GT01-C100R4-25P 10m
GT01-C200R4-25P 20m
GT01-C300R4-25P 30m
Computer
link
connection
cable
GT09-C30R4-6C 3m
For connecting computer link unit/serial
communication unit and GOT
GT09-C100R4-6C 10m
GT09-C200R4-6C 20m
GT09-C300R4-6C 30m
RS-232
Cable
QCPU
direct
connection
cable
GT01-C30R2-6P 3m
For connecting QCPU/Motion controller CPU (Q
series) and GOT
FX
expansion
board
connection,
FX special
adaptor
connection,
data
transfer
cable
GT01-C30R2-9S 3m
For connecting FXCPU expansion board (D-sub
9pins), special adapter (D-sub 9 pins) and GOT.
For connecting personal computer (GT
Designer2) (D-sub 9 pins: female)
*1
and GOT
(D-sub 9 pins: female)
*1
FX special
adaptor
connection
GT01-C30R2-25P 3m
For connecting FXCPU special adaptor (D-sub
25 pins) and GOT.
Computer
link
connection
cable
GT09-C30R2-9P 3m
For connecting computer link unit/serial
communication unit and GOT
GT09-C30R2-25P 3m
