16.1 BootOS and Standard Monitor OS Required for Installation
16.1 BootOS and Standard Monitor OS
Required for Installation
Under-mentioned BootOS and Standard monitor OS are necessary to execute utility.
OS name Function overview Storage location
BootOS
Required for the control of GOT and the communication between PC and GOT.
Installed at factory shipment.
(BootOS can be installed from GT Designer2 or the CF card. When installed
from GT Designer2 or the CF card, GOT is initialized to be the factory shipment
status.)
Flash memory
C: G1BOOT
Standard
monitor
OS
Standard monitor OS
Required for display and
operation of the user-created
screen and utility screen.
Not installed in GOT at factory
shipment.
Install it from GT Designer2 or
the CF card.
At installation, select Mincho or
Gothic for the 16-dot standard
font.
Flash memory
C:G1SYS
System Screen Data
System Screen Information
TrueType numerical font
12-dot Standard Font (Gothic)
16-dot Standard Font (Mincho)
16-dot Standard Font (Gothic)

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
