Mitsubishi GOT1000 GT11 User Manual

13 - 11
13.2 OS Information
13.2.4 Operation of OS information
3 Upload operation
BootOS and OS in the C drive (Flash memory) can be uploaded to the A drive (Built-in CF card).
1 Install the CF card used as the uploading
destination to GOT. Refer to the following
for inserting/removing method of CF card.
Section 8.1 CF Card
2 Touch [A: Built-in CF Card] of [Select
drive].
3 Touching starts the uploading.
4 When the upload is completed, the dialog
shown left is displayed.
Touching closes the dialog.
OS information screen
OS information screen: Storage file/folder display screen
2
3
Upload
OK

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
