3 - 2
3.2 Performance Specifications
3.2 Performance Specifications
• GT1155-QSBD, GT1150-QLBD
*1: Bright dots (always lit) and dark dots (unlit) may appear on a liquid crystal display panel. It is impossible to
completely avoid this symptom, as the liquid crystal display comprises of a great number of display elements.
Flickers may be observed depending on the display color.
Please note that these dots appear due to its characteristic and are not caused by product defect.
*2: The GOT screen saving/backlight off function prevents images from becoming permanently etched on the display
screen and increases the backlight life.
*3: ROM in which new data can be written without deleting the written data.
*4: Compliant with IP67 when the USB environmental protection cover is attached. Not compliant when a USB cable
is connected. Note that this does not guarantee all user’s operation environment.
Item
Specifications
GT1155-QSBD GT1150-QLBD
Display
section
*1
Type STN color liquid crystal STN monochrome (white/black) liquid crystal
Screen size 5.7"
Resolution
320 240 dots
Display size
W115(4.53) H86(3.39)[mm](inch) (Horizontal format)
Display character
16-dot standard font: 20 characters
15 lines, 12-dot standard font: 26 characters 20 lines
(Horizontal format)
Display color 256 colors Monochrome (white/black), 16 scales
Display angle
Left/Right: 50 degrees, Top: 50 degrees,
Bottom: 60 degrees (Horizontal format)
Left/Right: 45 degrees, Top: 20 degrees,
Bottom: 40 degrees (Horizontal format)
Contrast adjustment 16-level adjustment
Intensity of LCD only
350[cd/m
2
](Adjustable in 8 levels) 220[cd/m
2
](Adjustable in 8 levels)
Intensity adjustment 8-level adjustment
Life
*2
Approx. 50,000h. (Time for display intensity to become 1/5 at operating ambient temperature
of 25 ) Guaranteed: 1 year
Backlight
Cold cathode fluorescent tube (irreplaceable by a user) backlight shutoff detection function is
included.
Backlight off/screen saving time can be set.
Life
Approx. 75,000h or longer. (Time for display
intensity reaches 50% at the operating
ambient temperature of 25 )
Guaranteed: 1 year
Approx. 54,000h or longer. (Time for display
intensity reaches 50% at the operating
ambient temperature of 25 )
Guaranteed: 1 year
Touch
panel
Number of touch keys
300 keys/screen (Matrix structure of 15 lines
20 columns)
Key size
Minimum 16
16 dots (per key)
Number of points
touched
simultaneously
Maximum of 2 points
Life 1 million times or more (operating force 0.98N max.)
Memory
C drive
*3
Flash memory (Internal), for storing project data (3Mbytes) and OS
Life (Number of
write times)
100,000 times
D drive SRAM (Internal), 512kbyes (battery backup)
Battery GT11-50BAT lithium battery
Backup target Clock data, alarm history and recipe data
Life
Approx. 5 years (Operating ambient temperature of 25 ), Guaranteed: 1 year
Buzzer output Single tone (tone length adjustable)
Environmental protective
structure
*4
Equivalent to IP67 (JEM1030) (front section) when the USB environmental protective cover is
attached
External dimensions
W164(6.46)
H135(5.32) D56(2.21)[mm](inch)(Excluding USB environmental protective
cover) (Horizontal format)
Panel cutting dimensions
W153 (6.03)
H121(4.77)[mm] (inch) (Horizontal format)
Weight 0.7kg (Excluding mounting fixtures)
Compatible software package GT Designer2 Version2 or later
To Next Page
