Mitsubishi GOT1000 GT11 - Installation Method When the GOT Is Turned on

16 - 5
16.3 BootOS and Standard Monitor OS Installation Using CF Card
16.3.1 Installation method when the GOT is turned on
9
UTILITY FUNCTION
10
COMMUNICATION INTERFACE SETTING
11
DISPLAY AND OPERATION SETTINGS
12
CLOCK SETTINGS AND BATTERY STATUS DISPLAY
13
FILE DISPLAY AND COPY
14
GOT SELF CHECK
15
CLEANING OF DISPLAY SECTION
16
INSTALLATION OF BOOTOS AND STANDARD MONITOR OS
16.3.1 Installation method when the GOT is turned on
The displayed message is different depending on the installation condition of Standard monitor OS. When
the screen requesting operation is displayed, operate the GOT according to the instructions on the screen.
1 Operation procedure
1 Power OFF GOT and CF card access
switch. Insert the CF card in which
BootOS, Standard monitor OS or project
data is stored in the CF card interface of
GOT.
2 Switch ON the CF card access switch of
GOT.
3 Power ON the GOT touching the upper and
lower left corners of the GOT screen.
4 BootOS and Standard monitor OS are
installed in the built-in Flash memory.
5 The CF card access LED is lit during
installation.
Do not pull out the CF card or power off the
GOT while the CF card access LED is lit.
6 GOT restarts automatically after installation
is completed.
(When Standard monitor OS is already
installed, touch the button to reboot
the GOT.)
7 After confirming that GOT restarted
normally, switch OFF the CF card access
switch of GOT.
8 Confirm the CF card access LED is
extinguished, remove the CF card from the
CF interface of GOT.
OK
