3 - 1
3.1 General Specifications
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
PART NAME
5
EMC DIRECTIVE
6
INSTALLATION
7
WIRING
8
OPTION
3. SPECIFICATIONS
3.1 General Specifications
*1 : STN liquid crystal type to be stored at or below 39 WBT.
*2 : Do not use or store the GOT under pressures higher than the atmospheric pressure of altitude 0m (0ft.). Failure
to observe this instruction may cause a malfunction.
*3 : This indicates the section of the power supply to which the equipment is assumed to be connected between the
public electrical power distribution network and the machinery within the premises.
Category II applies to equipment for which electrical power is supplied from fixed facilities.
The surge voltage withstand level for up to the raged voltage of 300 V is 2500 V.
*4 : This index indicates the degree to which conductive pollution is generated in the environment where the
equipment is used.
In pollution degree 2, only non-conductive pollution occurs but temporary conductivity may be produced due to
condensation.
Item Specifications
Operating
ambient
temperature
Display
section
0 to 50
Other than
display section
0 to 55 (when horizontally installed), 0 to 50 (when vertically installed)
Storage ambient temperature
-20 to 60
Operating ambient humidity
*1
10 to 90% RH, non-condensing
Storage ambient humidity
*1
10 to 90% RH, non-condensing
Vibrationresistance
Compliant
with JIS
B3502 and
IEC61131-2
Frequency Acceleration
Half-
amplitude
Sweep Count
Under
intermittent
vibration
5 to 9Hz - 3.5mm
10 times each
in X, Y and Z
directions
9 to 150Hz
9.8m/s
2
-
Under
continuous
vibration
5 to 9Hz - 1.75mm
9 to 150Hz
4.9m/s
2
-
Shock resistance
Compliant with JIS B3502, IEC 61131-2 (147 m/s
2
, 3 times each in X, Y and Z
directions)
Operating atmosphere
Must be free of lamp black, corrosive gas, flammable gas, or excessive amount of
electroconductive dust particles.
Operating altitude
*2
2000 m (6562 ft) max.
Installation location Inside control panel
Overvoltage category
*3
II or less
Pollution degree
*4
2 or less
Cooling method Self-cooling
