Mitsubishi GOT1000 GT11 User Manual

2 - 11
2.2 Component List
2.2.2 Option (Optional components for GT11)
Drawing software (Sold separately)
* 6: The is assigned with an integer 2 or more.
PC connection cable (Sold separately)
* 7: Connector shape on the cable is shown in ( ).
Bar code reader (Sold separately)
*8: Some models with the operations checked by our company are usable.
For the operation-checked models, refer to "List of valid devices applicable for GOT1000 series" separately
available (T10-0039).
The Technical News above is available as a reference at the Information site for Mitsubishi industrial automation
products MELFANSweb home page.
(MELFANSweb home page: http://wwwf2.mitsubishielectric.co.jp/melfansweb/english/index_e.htm)
Product name Model name Contents
GT Designer2
SW
D5C-GTD2-E
( indicates the version)
*6
Drawing software for GOT1000/GOT900 series
Product name Model name Contents
Project data
transfer cable
GT01-C30R2-9S Cable length 3m
For connecting GOT (D sub 9-pin female)
and PC (D sub 9-pin female)
*7
GT01-C30R2-25P Cable length 3m
For connecting GOT (D sub 9-pin female)
and PC (D sub 25-pin male)
*7
GT01-C20USB-5P Cable length 2m
For connecting GOT (USB mini)
*7
and PC
(USB)
GT09-C30USB-5P Cable length 3m
Product name Model name Contents
Bar code reader -
Commercially-available bar code reader
*8

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
