Mitsubishi GOT1000 GT11 User Manual

8 - 2
8.1 CF Card
8.1.2 Installing and removing procedures of the CF card
8.1.2 Installing and removing procedures of the CF card
Install/remove the CF card with the power supply of GOT is OFF or CF card access switch is "OFF".
1 Installing
1 Set the CF card access switch of the GOT to "OFF", and make sure
that the CF card access LED turns off. (When the CF card access LED
turns off, the CF card can be installed even during the GOT power on.)
2 To install the CF card to the GOT, insert the CF card into the CF card
interface with its front side outside.
Push-in the CF card until the CF card eject button snaps.
3 Turn the CF card access switch on.
After the CF card access switch is turned on, the CF card can be used.
CF card access
switch
CF card
access LED
CF card
I/F
24V DC
INPUT
+-
CF card
GT1155-QSBD, GT1150-QLBD
CF card
CF card
front face
CF card front face
CF card
eject
button

Mitsubishi GOT1000 GT11 Specifications

General

Power Supply	24V DC
Operating Temperature	0 to 50°C
Storage Temperature	-20 to 60°C
Screen Size	5.7 inches
Resolution	320 x 240 pixels
Communication Interface	RS-422/485, USB
Memory	Internal flash memory
CPU	RISC
Touch Panel	Analog Resistive
